SpeedyBee F7 Mini 20x20 Flight Controller

• Available Pre order Out of stock
• Free Shipping
$49.99
Quantity

Payment Methods

Description

The SpeedyBee F7 Mini FC has come to change the way you deal with electronics. Flash, update, configure, all without having to plug into any computer. With the SpeedyBee app, you can change almost any parameter wirelessly!

Includes

  • 1x F7 Flight Controller
  • 1x Manual and App Download Card
  • 1x 8pin JST Cable
  • 5x M2 Grommets
  • 5x M3 Grommets

Specifications

Specifications

SpeedyBee F7 Mini FC

Input Voltage: 3-6S
MCU: STM32F722
Gyro: MPU6000
Barometer: No
OSD Chip: AT7456E
Bluetooth: Yes
DJI Air Unit Soldering Pads: Supported
BlackBox: 8MB Flash
Current Sensor: Yes
BEC: Yes
ESC Signal Pads: 4
UARTs: 3(UART1, UART2, UART3)
ESC Telemetry: R4(UART4)
LED Pad: Used for WS2812 LED
Buzzer: Yes
Firmware: BetaFlight(Default), EMUFlight, INAV
Firmware Target: SPEEDYBEEF7MINI
Mounting Dimensions: 20 x 20mm, 3.5mm hole diameter
Weight 5.7g
