casia-g

Available Pre order Out of stock
• Free Shipping
$500.00
Quantity

Payment Methods

Description

Ground based detect and alert system

Casia G leverages the same AI and computer vision technology pioneered by our onboard systems – but stationary – to detect aircraft as they approach your UAS operation.

Safety at the core

Protect airspace for uncrewed air vehicles and crewed aircraft to operate safely. Casia G features extremely high detection rates for reliable and predictable performance.

Detect intruder aircraft

Full optical, 360° field of view aircraft detection, classification (small plane, helicopter, drone, etc.) and alerting system

Gain situational awareness

Casia G can be integrated with your existing situational awareness tool to provide your Remote Pilot in Command (RPIC) access to all information from one system

Network for unlimited range

Leverage multiple Casia G nodes in the form of a mesh network to cover large areas and gain additional time to move UAS to safe zones

Operational assurance

Never tired, bored, or distracted – Casia G is a ground based surveillance system that continually monitors the airspace to ensure your UAS operation is safe from intruder aircraft.

Performance validated by the Mid-Atlantic Aviation Partnership (MAAP) at Virginia Tech, an FAA-designated UAS Test Site.

Turnkey solution
Installation and maintenance provided by Iris Automation support engineers

Reserves UAS payload
Without the need for onboard safety sensors, UAS power and payload capacity is made available

Scalable operations
Cost-effective with minimal management overhead. RPIC can manage multiple drones and increase the scope and efficiency of operations

Unlimited Coverage
Add additional Casia G nodes to create a larger network of coverage

No FCC approval required
Unlike radar, Casia G is a passive system and does not need an FCC approval



Specifications

TECHNICAL SPECIFICATIONS

Range: Multi-node network: Unlimited

Single - node Max Range: 3024m

Single - node Average Range: 2126m

Temp: -10ºC to 50ºC

Weight: 4 kg

Conditions: Daytime Visual Meteorological Conditions

Power: 65W nominal, 70W peak, 12-36V

Mount options: Various (wall, pole, etc.)

Dimensions: 14″L x 11.5″W x 6″H per node
